Dry freight van with a tail lift on a HINO 300 — the complete body, front three-quarter view from the left — COND

Dry freight van with a tail lift on a HINO 300 — right-hand side: the side door into the body — COND

Dry freight van with a tail lift on a HINO 300 — HINO 300 cab, close up — COND

Dry freight van with a tail lift on a HINO 300 — rear: the shutter raised and the tail lift platform deployed — COND

Dry freight van with a tail lift on a HINO 300 — the tail lift in working position, shutter open — COND

Dry freight van with a tail lift on a HINO 300 — side view: the tail lift platform lowered to the ground — COND

Dry freight van with a tail lift on a HINO 300 — the body from the rear, tail lift platform at ground level — COND

⚪ Completed · built to order

Dry freight van with a tail lift on a HINO 300

category CDhollandia tail liftside door

⬆ tail lift 1,000 kg🚪 rear loading from ground level

A dry freight van built for loading without a ramp. It has no rear swing doors: the opening is closed by a lifting shutter, and below sits a Dhollandia tail lift — the platform lowers to the ground, cargo is rolled on with a pallet truck and raised into the body. The tail lift plate states a 1,000 kg limit. A side door is cut into the right-hand wall: small items go in through it without opening the rear. On body construction, see the section on dry-freight bodies.

Get a quote for the same →WhatsApp

Chassis

Make / model	HINO 300, model 817
Class	a Japanese-built delivery truck
Cab	single
Rear wheels	twin
Vehicle category	C

Van

Body type	dry-freight (non-insulated) body
Rear portal	lifting shutter instead of swing doors
Tail lift	Dhollandia, 1,000 kg per the rating plate
Side door	yes, on the right-hand side
Fit-out	reflective corner markers around the perimeter, mudflaps, side underrun protection
Manufacture	the COND plant, Almaty

More about the design on the page dry-freight bodies.

FAQ

FAQ about the HINO 300 van with a tail lift

You have a ramp at your own warehouse; the delivery point usually does not. The truck carries its tail lift with it: the platform lowers to the tarmac, cargo is rolled on with a pallet truck and lifted into the body. The driver unloads alone — no loaders, no forklift waiting at the door.

The Dhollandia rating plate states a limit of 1,000 kg. The plate is visible in the photo of the mechanism — we deliberately left it in frame. The limit assumes an evenly distributed load: the further the pallet stands from the body, the smaller the margin.

Swing doors open outwards and foul the raised tail lift platform. So the rear opening is closed by a single shutter that lifts upwards: the platform works across the full width of the body and hits nothing.

No. The mechanism mounts to the frame and the rear opening, so the body above it can be anything — insulated, a reefer, a curtain-side. The only difference is how the rear opening is arranged and how much room is left under the body floor.

Yes. The HINO 300 exceeds 3,500 kg gross, which means category C. If you need a van drivable on category B, see the light-chassis projects in the “Vehicles” section.
